Open-source AS2 EDI gateway powered by AWS serverless

Website • Documentation • Quick Start • Community

---

ServerlessAS2 is a fully serverless implementation of the AS2 (Applicability Statement 2) protocol for secure B2B document exchange. Deploy your own AS2 gateway on AWS with zero server management, automatic scaling, and pay-per-use pricing.

Why ServerlessAS2?

Pain Point	ServerlessAS2 Solution
High monthly minimums	$0 on Free Tier; pay only for what you use
Complex, time-consuming setup	One command, 15 minutes — ready to trade
Manual XML configuration	Web UI for everything — pure point-and-click
Certificate management headaches	Centralized UI with expiration tracking
Difficult to scale	Auto-scales with automatic capacity
Vendor lock-in	Open source, runs on your AWS account — you own it

Features

One-Command Setup Single command deploys everything. 15 minutes from zero to production.

Free on AWS Free Tier $0/month for low volume. Pay only when processing messages.

Web UI Manage partners, certificates, and transactions visually. No XML configs.

Production-Proven Battle-tested with major trading partners across retail, logistics, healthcare, and finance.

100% Serverless Architecture

• Auto-scales to thousands of messages per second
• Built-in HA with Lambda + DynamoDB redundancy
• Multi-region capable for global disaster recovery
• Zero maintenance - fully managed AWS services

Quick Start

Deploy ServerlessAS2 to your AWS account with a single command in AWS CloudShell:

curl -fsSL https://serverlessas2.io/install.sh | bash

The installer will:

• Check prerequisites (AWS CLI, Node.js, Java, Maven)
• Configure your AWS region and settings
• Deploy all infrastructure via CDK
• Output your AS2 endpoint URL and admin console link

For manual installation or custom configurations, see Deploy to AWS.

Architecture

Component	Service	Purpose
Frontend	CloudFront + S3	Static web hosting for Vue.js admin console
Authentication	Cognito User Pool	User authentication and authorization
Backend API	API Gateway + Lambda	RESTful API for management operations
Database	DynamoDB	Store partners, certificates, partnerships, logs
Async Jobs	SQS + Lambda	Background processing for AS2 message delivery
Logging	CloudWatch Logs	Centralized logging and monitoring
Infrastructure	AWS CDK	Infrastructure as Code deployment

Cost Comparison

Solution	Monthly Cost (Low Volume)	Monthly Cost (1000 msgs/day)
ServerlessAS2	$0 (free tier)	~$1-3
AWS Transfer Family AS2	$220+ (always-on)	~$500+
OpenAS2 on EC2	~$15-30 (t3.small 24/7)	$30+
Commercial SaaS	$500-2000+	$500-2000+

Documentation

• Getting Started
• Configuration Guide
• Certificate Management
• Partnership Setup
• FAQ

---

Development

Want to contribute or run ServerlessAS2 locally? Follow the setup below.

Prerequisites

Tool	Version	Check
Node.js	18+	node --version
Java	17+	java --version
Maven	3.8+	mvn --version
AWS CLI	2.x	aws --version
AWS CDK	2.x	cdk --version

Clone the Repository

git clone https://github.com/Windingflow/ServerlessAS2.git
cd ServerlessAS2

Project Structure

serverlessas2/
├── backend/          # Java 17 + Quarkus Lambda functions
│   ├── src/main/java/com/windingflow/lambda/
│   │   ├── handler/      # Lambda entry points
│   │   ├── service/      # Business logic
│   │   ├── pojo/         # Data models
│   │   └── component/    # AWS SDK integrations
│   └── pom.xml
├── frontend/         # Vue 3 + TypeScript admin console
│   ├── src/
│   │   ├── views/        # Page components
│   │   ├── api/          # Axios API client
│   │   ├── router/       # Vue Router
│   │   └── store/        # Vuex state management
│   └── package.json
├── cdk/              # AWS CDK infrastructure (Java)
│   └── src/main/java/com/myorg/
│       ├── ResourceNames.java        # Centralized resource naming
│       ├── ManageLambdaStack.java
│       ├── AS2ReceiverLambdaStack.java
│       ├── S3EventLambdaStack.java
│       ├── SQSLambdaStack.java
│       └── FrontendDeploymentStack.java
└── deploy.sh         # Deployment script

Deploy to AWS

The deploy.sh script handles the full deployment: building backend, bootstrapping CDK, and deploying all stacks.

# In AWS CloudShell (auto-detects account/region)
./deploy.sh

# Specify account and region explicitly
./deploy.sh -a 123456789012 -r us-west-1

# With environment (dev, staging, prod)
./deploy.sh -a 123456789012 -r us-west-1 -e staging

# With AWS profile
./deploy.sh -p my-profile

# Non-interactive mode (for CI/CD)
./deploy.sh -y

# Combine options
./deploy.sh -a 123456789012 -r us-west-1 -e prod -p my-profile -y

Option	Description
-a, --account	AWS Account ID (auto-detected in CloudShell)
-r, --region	AWS Region (auto-detected from AWS_REGION)
-e, --environment	Environment name: dev, staging, prod (default: dev)
-p, --profile	AWS CLI profile (for SSO, run aws sso login --profile <name> first)
-y, --yes	Skip confirmation prompts
-q, --quiet	Less verbose output

The script will auto-install Maven if missing (Amazon Linux, RHEL, Ubuntu, Debian, macOS).

Deploy individual stacks manually:

cd cdk
cdk deploy ManageLambdaStack-dev-us-west-1
cdk deploy AS2ReceiverLambdaStack-dev-us-west-1
cdk deploy SQSLambdaStack-dev-us-west-1
cdk deploy S3EventLambdaStack-dev-us-west-1
cdk deploy FrontendDeploymentStack-dev-us-west-1

Running Tests

# Backend unit tests
cd backend && mvn test

# Frontend linting
cd frontend && npm run lint

---

Contributing

We welcome contributions of all kinds!

How to Contribute

1. Fork the repository
2. Create a feature branch

   git checkout -b feature/your-feature-name

3. Make your changes
4. Test your changes locally
5. Commit with a clear message

   git commit -m "feat: add support for async MDN"

6. Push to your fork

   git push origin feature/your-feature-name

7. Open a Pull Request

Commit Convention

We use Conventional Commits:

Type	Description
feat	New feature
fix	Bug fix
docs	Documentation only
refactor	Code change that neither fixes a bug nor adds a feature
test	Adding or updating tests
chore	Maintenance tasks

What to Contribute

• Bug fixes
• New features (please open an issue first to discuss)
• Documentation improvements
• Test coverage
• Performance optimizations

See open issues for ideas.

---

Community

• GitHub Discussions - Questions & ideas
• GitHub Issues - Bug reports & feature requests

Acknowledgements

This project is built on top of OpenAS2, the excellent open-source Java implementation of the AS2 protocol. We're grateful to the OpenAS2 community for their years of work building a robust, production-ready AS2 library.

ServerlessAS2 wraps OpenAS2's core protocol handling and extends it with:

• AWS Lambda-native execution
• Serverless infrastructure via CDK
• Modern web-based management console
• Cloud-native storage and queuing

If you find ServerlessAS2 useful, please also consider starring OpenAS2.

License

This project is licensed under the GNU General Public License v3.0 - see the LICENSE file for details.

---
